HMC7056A（Ka-Band Block Upconverter with HPA）-AD代理

HMC7056A的基本参数

制造厂商：AD/ADI（Analog Devices，亚德诺半导体）
产品类别：RF连接器模块和仪器仪表
技术类目：上变频器模块
功能描述：Ka-Band Block Upconverter with HPA
（AD代理渠道，提供当日发货、严格的质量标准，满足您的目标价格）

HMC7056A的产品详情：

The HMC7056A is a fully integrated Ka-Band BlockUpconverter with HPA. The unit is designed for singlecarrier use in satellite communications. It covers bothCommercial and Military bands and is designed tomeet military environmental conditions.

Applications

Satellite communications
Commercial
Military

HMC7056A的优势和特点：

Compact Design
Dual L Band Inputs
Dual up conversion to ensure no phase inversion
WR28 Output with Isolator
PA Enable

Digital Gain control
Thermal Monitoring and Gain Compensation
Size: 5.72” x 4.51” x 1.63”
Weight: 2.11 lbs
Designed for Military Environments

HMC7056A具体的完整产品型号参数及价格（美元）：

HMC7056A，封装：MODULE CONNECTORIZED，包装形式及数量：托盘，1，工作温度：-20 to 80C，AD官网报价：24052（100-499个）

HMC7056A-X，封装：MODULE CONNECTORIZED，包装形式及数量：托盘，0，工作温度：-20 to 80C，AD官网报价：

HMC7056A的评估套件：

HMC7056A的电路图解：

HMC7056A的评估套件：
