HMC362-DIE（InGaP HBT Divide-by-4 Chip, DC

HMC362-DIE的基本参数

制造厂商：AD/ADI（Analog Devices，亚德诺半导体）
产品类别：分频器、乘法器与检波器
技术类目：分频器、预分频器与计数器
功能描述：InGaP HBT Divide-by-4 Chip, DC - 11 GHz
（AD代理渠道，提供当日发货、严格的质量标准，满足您的目标价格）

HMC362-DIE的产品详情：

The HMC362 is a low noise Divide-by-4 Static Divider with InGaP GaAs HBT technology that has a small size of 1.30 x 0.69 mm. This device operates from DC (with a square wave input) to 11 GHz input frequency with a single +5V DC supply. The low additive SSB phase noise of -149 dBc/Hz at 100 kHz offset helps the user maintain good system noise performance.

Applications

Satellite Communication Systems
Fiber Optic
Point-to-Point Radios
Point-to-Multi-Point Radios
VSAT

HMC362-DIE的优势和特点：

Ultra Low SSB Phase Noise:
-149 dBc/Hz
Wide Bandwidth
Output Power: -6 dBm

Single DC Supply: +5V
Small Size: 1.30x 0.69 x 0.1 mm

HMC362-DIE具体的完整产品型号参数及价格（美元）：

HMC362，封装：CHIPS OR DIE，包装形式及数量：托盘，50，工作温度：-40 to 85C，AD官网报价：23.59（100-499个）

HMC362-SX，封装：CHIPS OR DIE，包装形式及数量：托盘，2，工作温度：-40 to 85C，AD官网报价：52.06（100-499个）

HMC362-DIE的评估套件：

HMC362-DIE的电路图解：
